MIL-DTL-43455K
Seam and
Stitches Per
Thread
Thread
Stitch Type Stitching
No.
Manufacturing Operations Requirements
Inch
Needle
Bobbin/
Type
(4) Turn up pocket and stitch through seam
301
LSbl-2(a)
10-14
30
30
allowance of cut-opening and raw edges of flap
through bearer and underply of pocket.
d. Safety stitch the plies of pocket along sides
50 1/
515 or
SSa-2
10-14
50
and across bottom folded edge. The lower
516 or
corners may be slightly rounded. If
(chain stitching)
overedging is equipped with knife, the bottom
519
(all overedge
folded edge of pocket shall not be cut.
stitching threads)
1/ or 40 conforming to type IV or V, class 1,
subclass B of V-T-285.
e. Applicable to construction in operation
11.c. only. Turn down flap and raise stitch
through all plies 3/16 to 1/4 inch from flap
301
10-14
30
30
joining seam. Continue the stitching above
both ends with the tongues turned in and
caught in the stitching.
f. Vertically bartack both ends of pocket
28 per
Bartack
30
30
opening with a 1/2 inch bartack superimposed
bartack
on stitching.
g. Attach the stud part of snap fastener
through front of coat and outer ply of pocket,
to correspond with socket part on pocket flap.
12
Make and set two breast pockets.
Finished appearance. The outside bellows
patch pockets shall be uniform in appearance,
without twists, puckers, pleats, or raw edges.
NOTE: The breast pocket shall be set on with
fullness at the top of the pocket. The width of
the top of the pocket shall be governed by the
size of the finished flap.
a. Seam and raise stitch bottom corner of
301 or
LSq-2
10-14
30
30
bellows portion of pockets, or stitch the
301
SSa-2
10-14
30
30
corners with two rows of stitching 1/16 to 3/32
inch apart.
b. Form bellows along back and bottom ends
of pocket and stitch 1/16 to 1/8 inch from
301
OSf-1
10-14
30
30
inside and outside folded edges forming
bellows.
c. Make a triangular hem at top of pocket, 2 +
1/4 inches wide at center with raw edge turned
under and single stitch 1/16 to 1/8 inch from
301
EFb-1
10-14
30
30
edge. The top back of the bellows shall be
inserted within the hem and caught in the
stitching.
21
