MIL-DTL-6279M
NO.
OPERATION
STCH
SEAM/STCH
STITCHES PER
TYPE
TYPE
INCH
j. Turn and raise stitch the
pocket with a single row of
stitching 1/16 inch from the
edge of the pocket.
10-12
LSb-1
301
k. As an alternate to 6.i and 6.j,
fold under the front edge of the
pocket 1/4 to 3/8 inch, and with
slide fastener face side up,
stitch front edge to the left side
of the slide fastener tape 1/16
inch from the folded edge. The
slider shall be at the top of the
pocket when the slide fastener
is closed.
10-12
LSd-1 or LSa-1
301
and LSa-1
l. Stitch the front edge of the
slide fastener tape to the left
topsleeve at the drill marks.
Turn the raw edge of the pocket
under 1/4 inch, and stitch all
sides with a single row of
stitching 1/16 inch from the
edge. The slide fastener tape
shall be turned under at the top
and bottom ends.
10-12
SSa-1
301
m. A second row of stitching
shall be placed 1/4 inch from
the front edge of the tape and
across the top of the pocket.
JOIN SLEEVES
7.
ELBOW PATCHES
10-12
LSd-2
301
a. Turn under raw edges of
elbow patches 1/2 inch and
attach to sleeve with a double
row of stitching, with the first
row of stitching 1/16 inch from
turned edge, with a 1/4 inch
gage.
6-8
LSc-2
301 or 401
19
