MIL-DTL-6279M
NO.
OPERATION
STCH
SEAM/STCH
STITCHES PER
TYPE
TYPE
INCH
stitching (optional).
d. Slit the fold through the
center to make pencil pass-
through. The pencil
compartment may be made in
two pieces.
10-12
LSd-2
301
e. Join the pencil compartment
to the utility compartment with
a double row of stitching 1/4
inch gage, 1/16 to 1/8 inch from
the edge, along both sides in
accordance with the notches
and the drill marks, with the
bottom edges even.
10-12
SSv-1
301
f. Place a single row of
stitching centered between the
front edge and the back edge
the entire length of the pencil
compartment to separate
openings.
28 per brtck
Brtck
g. Bartack the top ends of all
pencil compartment openings,
with the bartacks superimposed
on the inner row of double
stitching and on the center row
of stitching. Bartacks shall be
3/8 to 1/2 inch long.
10-12
SSa-1
301
h. Form a 3/4 inch bellows by
joining the two bottom corners
with a single row of stitching
1/4 inch from the edge.
10-12
LSq-2 (a)
301
i. Seam the slide fastener tape
to the forward side of the
pocket with a 1/4 inch seam.
The slider shall be at the top of
the pocket when the fastener is
closed.
10-12
LSq-2 (b)
301
18
