MIL-DTL-44419A
Table V. Waterproof insert requirements
Mullen Hydrostatic Resistance
Initial
20 psi min.
After DEET (diethyltoluamide) insect repellent reagent
16 psi min.
Chemical Penetration Resistance
No leakage
Water Permeability after Universal Wear
150 cycles, no leakage
Abrasion Test
Water Permeability after DEET (diethyltoluamide)
No leakage
insect repellent reagent
3.3.5 Curved tension lock 3/4 inch. The 3/4 inch curved tension lock shall be ITW Nexus, Part
number GT LL 3/4 or equal. The color of the tension lock shall be Foliage Green 504. Testing
shall be as specified in 4.4.4. (See 6.7).
3.3.6 Tape Wrist Strap. The tape for the wrist strap shall be 3/4 inch wide conforming to
Class 2 of MIL-W-17337. The long wrist strap shall be folded 1-3/4 + 1/4 inch on one end and
stitched at both ends of the fold. The unfolded raw end shall be stitched into the glove. The short
wrist strap shall be folded in half and the raw edges stitched into the glove. The tape shall be cut
in sufficient lengths to meet the specified finished lengths in Table VI. (See Figures 2 and 3). All
tape raw edges shall be seared. The color shall be Foliage Green 504.
Table VI. Wrist strap lengths
Long wrist strap
Short wrist strap
finished length (inches)
finished length (inches)
X-Large Wide
7-3/8
1-1/2
X-Large
7
1-1/2
Large Wide
7-3/8
1-1/2
Large
6-7/8
1-1/2
Medium - Wide
7
1-1/2
Medium
6-1/2
1-1/2
Small
6-1/2
1-1/2
Tolerance
+ 1/4
+ 1/8
3.3.7 Glove hook. The glove hook shall be ITW Nexus, Part number 106-0100 or equal. The
color shall be Foliage Green, 504. Testing shall be as specified in 4.4.4. The glove hook shall be
placed on the side of the 1st digit on the right hand, and it shall be placed on the side of the 5th digit
on the left hand. They shall be placed 1/2-3/4 inch from top of gauntlet. (See 6.8).
3.3.7.1 Hook attachment material. A 3/8 inch wide ribbon or leather shall be used to attach the
glove hook. The cut length shall be 2 inches + 1/4 inch, with 1/4 inch seam allowance. The
distance of glove seam to glove hook on end item shall be 1/2 inch maximum + 1/4 inch.
9
