MIL-DTL-44419A
be a 13 digit national stock number (NSN). There shall be a 12 digit UPC number assigned for all
NSN's by the contracting activity. The initials "UPC" must appear beneath the code. The bar
code for NSN and UPC type shall be a medium to high density and shall be located so that it is
completely visible on the glove when it is folded and/or packaged as specified and so it causes no
damage to the glove. This UPC code must also be placed on all shipping cartons on which the
NSN appears.
3.9 Design. The gloves have a stretch fabric on the back of the hand, leather palms,
waterproof inserts and an insulated lining. The gloves shall be slip-on, inseamed fourchette design
with a two pattern piece thumb and a fleece snow cuff, containing a leather/fabric shell,
waterproof/moisture vapor permeable insert, microfiber insulation with brushed polyester/ nylon
lining, buckle/strap adjustment on the back of the wrist with an elastic take up opposite, and a
hook and dee for attaching gloves to each other.
3.10 Patterns. The government shall furnish a complete set of patterns or a master pattern with
grade rules, to maintain uniformity and consistency in manufacturing. The government patterns
shall be used to create the contractor's working pattern. Minor modifications are permitted to
accommodate manufacturing procedures, however, the design and finished measurements shall be
maintained. (See 6.4).
3.10.1 List of pattern parts. The components of the glove shall be cut from materials specified
in accordance with the parts specified in Table IX.
Table IX. List of pattern parts
Material
Pattern abbreviation
Nomenclature
Cut
Insulation
INSPB
Insulation Palm Back
2 (mirror)
INSD3D4
Insulation D3 D4
2 (mirror)
INSTPB
Insulation Thumb Palm Back
2 (mirror)
INSTD2
Insulation Thin D2
2 (mirror)
Leather
D1PALM
D1 Palm
2 (mirror)
D2D3F
D2 D3 Fourchette
2 (mirror)
D3D4F
D3 D4 Fourchette
2 (mirror)
D4D5F
D4 D5 Fourchette
2 (mirror)
D5F
D5 Fourchette
2 (mirror)
PALM
Palm
2 (mirror)
PALMP
Palm Patch
2 (mirror)
Fabric
GAUPALM
Gauntlet Palm
2
(Cut Fill)
GAUPBACK
Gauntlet Back
2
D1BACK
D1 Back
2
BACK
Back
2
Nosewipe material
NOSEWIPE
Nose Wipe
2 (mirror)
Fleece
WRISTLET
Wristlet
2
(Cut warp)
12
