MIL-DTL-85040D
3.7.1.2 Alternate label location. The identification label, may also be sewn to the outside of shirt
to avoid chafing, stitch 301, 8-10 SPI. 1/8" gauge.
3.7.2 Undershirt. The identification label, for the undershirt, shall be centered, within ½ inch,
and sewn to the back, on the inner side of the undershirt, ¼ inch below the collarette seam
reinforcement, as specified in Figures 5 and 11. The label shall be attached on the sides only
(vertical stitching) when the 2-sided stitch method is employed and around the label perimeter
when the 4 side stitch method is used. Labels shall be attached in such a manner that shall permit
the label to expand with the fabric of the undershirt. The label size and the information, for the
undershirts shall be as follows:
2-3/8 INCHES WIDE
CWU-44P UNDERSHIRT, FLYER'S ANTI-
EXPOSURE , ARAMID
SIZE
MIL-D-85040C
1-1/4
CONTRACT OR ORDER NUMBER
INCHES
DATE OF MANUFACTURE (Month and Year)
LONG
NSN
Wash in warm water (100°-120°F)
using detergent. Rinse thoroughly.
Tumble dry low. DO NOT BLEACH
(*)
XXXXXXXX
XXXXXXXX
(*) Allow label to have blank space for wearer to write his/her name.
3.7.2.1 Alternate label. As an alternate, the following label shall be attached to the undershirt in
the collarette seam during collar setting and shall be centered, (±1/2) inch at the back of the
neck. The label shall be 1-1/4 (± 1/2) inches wide and 1-1/2 (± 1/2) inches long. The label shall
have all required printing occurring on the front and back of the label, and the following
statement shall be printed on the label " DO NOT REMOVE THIS LABEL".
3.8 Workmanship. After completion of the final assembly, the drawers or undershirts, as
applicable, shall be thoroughly cleaned and all thread scraps, lint and foreign matter shall be
removed. The drawers and undershirts as applicable, shall not contain any tear, cut, mend, needle
chew, abraded area, burn, spot, stain, or hole. The drawers or undershirts, as applicable, shall be
uniform in quality and shall be free from irregularities or defects which could adversely affect
performance, reliability, or durability. The drawers or undershirts, as applicable shall conform to
the quality and grade of product established by this specification. The occurrence of defects shall
not exceed the acceptance criteria established herein.
9
