MIL-DTL-85040D
l. Sleeve inseam. Measure the length of each sleeve inseam, from the armhole seam to
the bottom of the cuff.
m. Shoulder width. Measure the distance, on each shoulder, from the collarette attaching
seam to the armhole seam.
n. Cuff length. Measure the length of each cuff, from the attaching seam to the end of
the cuff.
o. Cuff width. Measure the width of the cuff, at the unattached end, from side fold to
side fold.
p.
Mock turtleneck length. Measure the height of the mock turtleneck (collarette), from
the top fold to the attaching seam.
3.7 Label. The identification label, for the drawers and the undershirts, as applicable, shall
conform to MIL-DTL-32075, Type VI, Class 1, Launderable Label, except that the item
description shall be 8 point and all the other information shall be 6 point.
3.7.1 Drawers. The identification label, for the drawers, shall be centered, within ½ inch, and
sewn to the inner back portion, of the waistband, as specified in Figure 8, in a manner that shall
permit the label to expand with the waistband of the drawers. The top edge of the label shall be
aligned with the top edge of the waistband. The label shall be attached on the sides only (vertical
stitching) when the 2-sided stitch is employed or around the label perimeter when the 4-sided
stitch method is used. The label size and the information, for the drawers, shall be as follows:
2-3/8 INCHES WIDE
CWU-43P DRAWERS, FLYER'S ANTI-
EXPOSURE ARAMID
SIZE
MIL-D-85040C
1-1/4
CONTRACT OR ORDER NUMBER
INCHES
DATE OF MANUFACTURE (Month and Year)
LONG
NSN
Wash in warm water (100°-120°F)
using detergent. Rinse thoroughly.
Tumble dry low. DO NOT BLEACH
(*)
XXXXXXXX
XXXXXXXX
(*) Allow label to have blank space for wearer to write his/her name.
3.7.1.1 Alternate label. As an alternate, the following label shall be attached to the drawers in the
back seam during waistband setting and shall be centered, (±1/2) inch at the back of the
waistband. The label shall be 1-1/4 (± ½) inches wide and 1-1/2 (±1/2) inches long. The label
shall have all required printing occurring on the front and back of the label, and the following
statement shall be printed on the label " DO NOT REMOVE THIS LABEL".
8
