MIL-DTL-29112D
(C) SIDE LENGTH - Measure from bottom of waistband to bottom of finished hem, along
side seam.
(D) LEG OPENING - Fold inseam and outseam together, measure from the folded edge to the folded
edge of each leg opening with opening laid flat.
TABLE IV. Finished part measurements (inches) 1/
Swimmers Trunk Part (all sizes)
Finished Measurement (inches)
E. Waistband width
1-1/2 + 1/8
F. 1/2 belt width
1-1/8 + 1/16
G. 1/2 belt length (right)
6-1/4 + 1/4
H. 1/2 belt length (left)
11 + 1/4
I. Patch pocket width
5-1/2 + 1/4
J. Patch pocket length
5-1/2 + 1/4
K. Belt loop length
2 + 1/8
L. Belt loop width
5/8 + 1/16
1/ There are no figures for measurements E through L.
E. The waistband width shall be measured at the center back.
F. The 1/2 belt width shall be measured from edge to edge in the center of each 1/2 belt.
G. The length of the right 1/2 belt shall be measured from the edgestitching on the waist to the edge of
the fold where the belt passes through the D-rings.
H. The length of the left 1/2 belt shall be measured from edgestitching on the waist to the opposite
edge.
I. The pocket width shall be measured from edge to edge at the center of the pocket.
J. The pocket length shall be measured from edge to edge at the center of the pocket.
K. The belt loop length shall be measured from folded edge to folded edge.
L. The belt loop width shall be measured from edge to edge.
9
