MIL-DTL-29112D
LAUNDERING INFORMATION
Hand or Machine Wash in Cold or Warm Water
Do Not Bleach or Iron. Tumble Dry Low Setting (Medium Heat)
or
Use Navy Wash Formula II
Tumble Dry Medium Heat
3.7.1 Barcode label. The swimmer trunks shall have a printed individual bar-code label
that is clearly legible and readable by a scanner. The bar coding element shall be a 13 digit national
stock number (NSN). There shall be a 12 digit UPC number assigned for all NSNs by DSCP. The
initials UPC must appear beneath the UPC code. The bar code NSN and UPC types shall be a
medium to high code density and shall be located so that it is completely visible on the item when it is
folded and/or packaged as specified and so that it causes no damage to the item.
3.8 Finished measurements. The trunks shall be provided in the sizes and measurements in
accordance with Table III and Table IV.
TABLE III. - Sizes and measurements (in inches)
SIZES
(A) WAIST
(B) SEAT
(C) SIDE LENGTH
(D) LEG OPENING
28
28
36
10-3/4
11-3/4
30
30
38
10-7/8
12-1/8
32
32
40
11
12-1/2
34
34
42
11-1/8
12-7/8
36
36
44
11-1/4
13-1/4
38
38
46
11-3/8
13-5/8
40
40
48
11-1/2
14
Tolerance
+1, -1/2
+/- 1
+/- 1/4
+/- 1/4
NOTE: Measurements shall be taken with the trunks laid flat and smooth with fly
buttoned.
(A) WAIST - Measure the width across the top of waistband from folded edge to folded edge.
(B) SEAT - Measure across the seat from folded edge to folded edge approximately six (6) inches up
from bottom of trunks.
8
