MIL-DTL-83776B(USAF)
3.5.2 Thread breaks and ends of seams. Ends of all seams and stitching will be back tacked not less
than 1/4 inch. Ends of continuous line of stitching will overlap not less than 1/2 inch. Thread breaks will
be secured by stitching back of the break not less than 1/2 inch, unless otherwise specified.
TABLE II. Construction of the Helmet.
Seams and
Stitch
Stitching
Stitch per
No
Description of Operation
Type
Type
Inch
1
Cutting
a. Cut all parts in strict accordance with patterns
furnished which show size for proper a of all parts.
b. Cut the nylon outershell out of the same piece of
material.
c. Cut the satin, acetate or rayon all out of the same
piece of material.
2
Replacement of damaged parts. Replace at time of
cutting any part containing damages such as holes,
smashes, slubs or multiple floats.
b. Replace any part damaged, during
the manufacturing process, by a needle
chew, cut, tear, hole, mend or burn.
3.
Prepare helmet
a. The helmet will consist of a four-
panel innershell and a four-panel
outershell with a mouton front panel.
A webbing adjustment (chin strap) with
mouton chin strap guard fastened to
the outside side panels with four snap
fasteners.
.
8
