MIL-DTL-83776B(USAF)
TABLE II. Construction of the Helmet.(con't)
Seams and
Stitch
Stitching
Stitch per
No
Description of Operation
Type
Type
Inch
9.
Join the inner and outer head pieces (con't)
at the following three places: Center top where the
quarter seams meet and on each back quarter seam
l/4 + l/8 inch above the mouton. The center top may
be tacked by machine.
SSa-1
8-12
b. Place the outer and innershells face to face and
301
sew together around entire edge seam and close by
or
hand stitching.
401
7-10
c. Turn helmet through the 4 inch open seam and close Hand
SSc-1
8-12
by hand stitching.
or
301
10.
Chin strap
The chin strap will be fabricated by using one piece of
webing with raw edges of webbing abutting each other
at the center of the strap underneath the mouton chin
strap guard. In the course of sewing, the mouton
portion to the webbing, the raw edges of webbing will
be securely caught in the stitching.
Cleaning
11
a. Remove any spots.
b. Remove all thread ends.
.
Closing
12.
Fasten all snap fasteners.
3.6 Construction. The helmet will be constructed with all the operations listed in Table II. The
contractor is not required to follow the exact sequence of operations listed, provided the finished helmet
is identical to that produced by the following sequence of operations.
10
