MIL-DTL-83776B(USAF)
appear beneath the code. The bar code NSN and UPC type will be a medium to high code density and
will be located so that it is completely visible on the item when it is folded an/or packaged as specified
and so that it causes no damage to the item.
3.3 Patterns. Standard patterns, which provide 1/4 inch seam allowance will be furnished by the
Government and will not be altered in any way. They will be used only as a guide for cutting the
supplier's working patterns which will be identical to the standard patterns.
3.3.1 List of pattern parts. The pattern components for the helmet will be cut from materials as
specified and according to the number of parts listed in Table I.
TABLE I. List of Pattern Parts.
Material
Pattern Nomenclature
Cut Parts
Mouton
Neck and ear panel
1
Mouton
Chin strap guard
1
Mouton
Front panel
1
Cloth Nylon
Rear panel outershell
1
Cloth Nylon
Side panel outershell, face up
1
Cloth Nylon
Side panel outershell, back up
1
Cloth Nylon
Front panel outershell
1
Cloth Satin, Acetate or Rayon
Rear panel innershell
1
Cloth Satin, Acetate or Rayon
Side panel innershell, face up
1
Cloth Satin, Acetate or Rayon
Front panel innershell
1
Cotton Webbing
Chin strap (see 51D24313)
1
3.3.2 Marking. The components of the helmet will be marked to insure a uniform shade and size
throughout the garment. Any method of marking may be used except:
a. Corrosive metal fastening devices
b. Sew-on type tickets
c. Adhesive type tickets which discolor or adhere to the material upon removal of the tickets.
3.3.3 All parts will be marked, ticketed or bundled to insure uniform shade throughout the helmet.
When the bundle system is used, plies from each bolt of fabric will be separated (in the spreading) by
tissue paper or other identifying medla and the parts, after cutting will be so segregated that each bundle
will contain only parts cut from the same piece of material. The bundles must be identified so that all the
components for each end item will be from the same piece of material.
3.4 Design. The helmet is a fully lined cold weather head covering, having a four-piece crown, mouton
forehead, earflaps with a webbing chin strap that closes with snap fasteners
(see Figure 1).
