MIL-DTL-44105C
1. Initial loose fit required for continued comfort.
2. Hand or machine wash using permanent press cycle, cold water and
mild detergent without chlorine bleach.
3. Do not wring or twist. Rinse in clean, cold water.
4. Dry at low heat (do not exceed 130ºF) or hang dry.
CAUTION
Chlorine bleach or starch will damage the hat
Suspend headnet from top of brim, drape headnet over shoulders.
DO NOT REMOVE THIS LABEL
3.3.8.2.3 Combination identification-size-instruction label. As an alternate, a combination
identification-size-instruction label may be used. The label shall conform to Type IV, Class 14 of
MIL-DTL-32075, and shall contain the information specified in 3.3.8.2.1 or 3.3.8.2.2, as applicable.
3.3.8.2.4 Bar coding. Bar coding labels shall be applied as specified in the contract or order. (see 6.2)
3.4 Ventilators, with washers. The screen-type ventilators with washers shall be brass, tan in color for
Type II, have a black chemical finish for the Type III hat, and an antique brass finish for the Type IV
and V hat. The hat ventilators shall have a 9/16 + 1/16 inch opening with a No. 50-70 mesh and a 40 to
60% opening (see 6.5).
3.5 Design. Types II, III, IV and V hat shall be a lightweight, soft crowned model with a quilt-stitched
brim and chin strap. The hat shall be lined with self material. Type II, IV and V hats shall have a
camouflage band and shall be water repellent (see Figures 1 and 2).
3.5.1 Toxicity. The finished sun hat shall not present a health hazard and shall show compatibility
with prolonged, direct skin contact when tested as specified in 4.5.4 Chemicals recognized by the
Environmental Protection Agency (EPA) as human carcinogens shall not be used.
3.6 Patterns. Patterns which provide a 3/16 inch allowance for seaming side lining to crown, 3/8 inch
allowance for seaming brim to sides, and 1/4 inch allowance for all other seams, will be furnished by
the Government to the contractor for cutting working patterns. The Government patterns shall not be
altered in any way and are to be used only as a guide for cutting the contractor's working patterns. The
working patterns shall be identical to the Government patterns.
3.6.1 List of pattern parts. The components of the sun hat shall be cut from the materials specified and
according to the number of parts listed in Table III.
7
