MIL-DTL-44105C
TABLE VIII End item visual defects
Classification
Examine
Defect Description
Major
Minor
242
of band
1/
Camouflage band bartack measuring less than ½ inch or
1/
243
more than 5/8 inch
Camouflage band bartack measuring more than 3/32
inch wide
1/
244
Camouflage band bartack extending beyond edge of
245
1/
webbing
Camouflage band off center of bottom side piece by
246
more than 1/8 inch
1/
126
Chin strap and keeper
Chin strap missing
247
End of chin strap not fused
127
Keeper missing
Keeper less than 5/8 inch or more than 7/8 inch long; or
248
less than 3/8 inch or more than 5/8 inch wide
Holes in keeper too small or too large not permitting
chin strap to function properly (falls freely from set
128
position or keeper immovable
249
Chin strap length not within tolerance
250
Chin strap twisted
1/ This defect pertains to Types II, IV, and V Sun Hats only.
4.5.4 Toxicity test. When required, (see 6.2), an acute dermal irritation study and a skin sensitization study
shall be conducted on laboratory animals. When the results of these studies indicate the sun hat is not a
sensitizer or irritant, a Repeat Insult Patch Test shall be performed in accordance with the Modified Draize
Procedure. (See 2.3). If the toxicity requirement (see 3.5.1) can be demonstrated with historical use data,
toxicity testing may not be required (see 6.2).
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or
order (see 6.2). When actual packaging of material is to be performed by DoD or in-house contractor
personnel, these personnel need to contact the responsible packaging activity to ascertain requisite packaging
requirements. Packaging requirements are maintained by the Inventory Control Point's packaging activities
within the Military Department or Defense Agency, or within the military service's system commands.
Packaging data retrieval is available from the managing Military Department's or Defense Agency's automated
packaging files, CD-ROM products, or by contacting the responsible packaging activity.
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but is not
mandatory.)
6.1 Intended use. The sun hats are intended for special purpose wear by Department of Defense military
personnel. The Type II sun hats are to be worn in desert areas, Types III and V are to be worn in tropical and
semi-tropical areas, and the Type IV sun hat shall be worn in all environments.
19
