MIL-DTL-44105C
TABLE VII Finished measurements (inches)
Finished Measurements in inches
Inside hat
Crown height Crown height
Size
(head mea-
Brim width 4/
At center
At center
surements) 1/
Front 2/
Back 3/
6-3/8
20-1/2
2-3/4
3-1/2
2-3/8
6-1/2
20-7/8
2-3/4
3-1/2
2-3/8
6-5/8
21-1/4
2-3/4
3-1/2
2-3/8
6-3/4
21-5/8
2-3/4
3-1/2
2-3/8
6-7/8
22
2-3/4
3-1/2
2-3/8
7
22-3/8
2-3/4
3-1/2
2-3/8
7-1/8
22-3/4
2-3/4
3-1/2
2-3/8
7-1/4
23-1/8
2-3/4
3-1/2
2-3/8
7-3/8
23-1/2
2-3/4
3-1/2
2-3/8
7-1/2
23-7/8
2-3/4
3-1/2
2-3/8
7-5/8
24-1/4
2-3/4
3-1/2
2-3/8
7-3/4
24-5/8
2-3/4
3-1/2
2-3/8
7-7/8
25
2-3/4
3-1/2
2-3/8
8
25-3/8
2-3/4
3-1/2
2-3/8
Tolerance
+ 1/4
+ 1/4
+ 1/4
+ 1/8
1/
Measure along bottom edge of side lining.
2/
Measure from base of side to crown seam on outside of center front.
3/
Measure from base of side to crown seam on outside of center back.
4/
Measure from base of side to outer bound edge of brim.
3.12 Workmanship. The finished hat shall conform to the quality of product established by this
specification. The occurrence of defects shall not exceed the applicable acceptable quality levels.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as follows:
a. First article inspection (see 4.2).
b. Conformance inspection (see 4.3).
4.2 First article inspection. A first article, submitted in accordance with 3.1, shall be inspected, examined
for appearance, color and finished defects as specified in 4.5.2 and tested for the characteristics as specified
in 4.5.3. The sample size will be specified in the procurement document (see 6.2). The sample unit shall
be one hat and the lot size shall be expressed in units of hats.
4.3 Conformance inspection. Conformance inspection shall include the examination of 4.5 through 4.5.4
and the dimensional verifications of 4.5.3. Sampling for inspection shall be performed in accordance with
ANSI/ASQ Z1.4 and with acceptance quality limit as specified in the contract and/or order, except where
otherwise indicated. The sample unit shall be one hat and the lot size shall be expressed in units of hats.
4.4 Inspection Conditions. Unless otherwise specified, all inspections shall be performed in accordance
with all the requirements of referenced documents, unless otherwise excluded, amended, modified or
qualified in this specification or applicable procurement documents
15
