MIL-DTL-44048H
XX-Large X-Long
Height: 71 to 75 in
Chest: 53 to 57 in.
Stock No.
NATO Size 9000/2434
3.3.6.3 Label/tag. Each coat shall be individually bar-coded with a paper tag for personal clothing
items. The paper tag shall be standard bleached sulfate having a basis weight of 100 pounds. The
paper used for the tags shall have a smooth finish to accept thermal transfer and direct printing. The
tags shall have a hole and shall be attached to each coat by a fastener. The tags shall be clearly legible
and readable by scanner. The bar coding element shall be a 13 digit national stock number (NSN).
There shall be a 12 digit UPC number assigned for all NSNs by the contracting activity. The initials
"UPC" must appear beneath the code. The bar code for NSN and UPC type shall be a medium to
high density and shall be located so that it is completely visible on the coat when it is folded and/or
packaged as specified and so it causes no damage to the coat. This UPC code must also be placed on
all shipping cartons on which the NSN appears.
3.3.6.4 Label placement. The labels shall be securely attached to the coat and positioned as follows:
(1) Identification/care label. On inside of right lower front pocket area, for uniformity
between garments. No indication of label application shall show on the outside of the
coat. (See figure 2).
(2) Size label. On inside center collar (+ 1 inch off center), for visibility when folded.
(3) Insect repellent label. Attached to coat covering existing size or combination label.
3.3.7 Buttons. The buttons shall be dull finish, 4-hole, 30 ligne, and shall be in accordance with the
following button style:
(Cross section of button)
The color of the button shall be a good match to Camouflage Green for types I, VI, IX, X and XIII
coat, and Khaki for types VII and XI coat, and Black for types VIII and XII coat. The buttons shall
not exhibit chalking when tested as specified in 4.4.4. The buttons shall show a minimum compressive
strength of 1800 lb. when tested as specified in 4.4.5. When attached to the coat, the button and
thread shall withstand a pull test of 40 lb. (min.), when tested as specified in 4.4.6.
3.4 List of pattern parts. Standard patterns provide a seam allowance of 3/8 inch for single needle
seams and ½ inch for double needle seams. Buttonholes, pockets and pocket flaps shall be located in
8
