MIL-DTL-14610H
of dust accumulation.
Wash at low temperature. Dry
thoroughly.
Warning: Upon removal of garment,
brush off accumulated foreign
matter thoroughly.
3.7 Barcode. Each item shall be individually bar-coded with a tag for personal clothing items.
The tags shall be attached to each item, and shall be clearly legible and readable by a scanner.
The bar coding element shall be a 13 digit national stock number (NSN). The bar code type shall
be a medium to high code density and shall be located so that it is completely visible on the item
when it is folded and/or packaged as specified.
3.8 Recycled, recovered, or environmentally preferable materials. Recycled, recovered, or
environmentally preferable materials should be used to the maximum extent possible provided
that the material meets or exceeds the operational and maintenance requirements, and promotes
economically advantageous life cycle costs.
3.9 Patterns. The Government shall furnish a complete set of patterns or a master pattern with
grade rules. The government patterns shall be used to create the contractor's working patterns.
Minor modifications are permitted to accommodate manufacturing procedures, however, the
design and finished measurements must be maintained.
3.9.1 List of pattern parts. Table II is provided to insure that the pattern set is complete.
TABLE II. List of pattern parts
Nomenclature
Cut pieces
Top front
2
Top back 1/
1
2
Trouser front
2
Trouser Front extension (side entry)
2
Trouser back
1
Right front facing
2
Sleeve
2
Collar
2/
1/ The back may be cut in two pieces (1/2 inch seam allowance shall be added for a double-lapped, double-stitched
seam.)
2/ The collar may be cut in one piece (eliminate bottom edge seam allowance).
3.9.2 Finished measurements. The finished coveralls shall conform to measurements as shown
in Table III.
TABLE III. Finished measurements (inches)
Size
X-Small
Small
Medium
Large
X-Large
½ Chest 1/
20-1/2
22-1/2
24-1/2
26-1/2
28-1/2
½ Waist 2/
17-1/2
19-1/2
21-1/2
23-1/2
25-1/2
5
