MIL-DTL-27546E
Sleeve outseam 3/
35
35-1/2
36-1/4
37
+1
-3/4
1/2 Sleeve bottom 4/ 6
6-1/4
6-1/2
6-3/4
+ 1/4
circ. (top of knit)
Sweep 5/
19-1/2
21-1/2
24-1/2
25-1/2
+1/2, -3/8
1/ The measurement of the back length shall be taken, at the center of the back, from the undercollar seam
to the bottom of the jacket.
2/ The measurement of the chest shall be taken with the liner buttoned, from folded edge to folded edge in
line with the armhole.
3/ The measurement of the sleeve outseam shall be taken at the center back at the collar seam, diagonally
across the back, down the sleeve to the edge of the knit cuff.
4/ The measurement of the sleeve bottom shall be taken across the top of the knit cuff, with the bottom
stretched taut, using manual tension.
5/ The measurement of the sweep shall be taken, at the bottom of the jacket liner, from the folded edge to
folded edge of the jacket fully buttoned.
TABLE IV. Trouser Liner finished measurements (inches)
Small
Medium
Large
X-Large Tolerance
½ Relaxed waist 1/
12
14-1/2
17
19-1/2
+ 1/2 -1/4
circ.
Outseam 2/
38-1/4
39-3/4
41-1/4
42-3/4
+ 3/4
Inseam 3/
26-3/4
27-1/4
27-3/4
28-1/4
+ 1/4
½ Bottom circ. 4/
6
6-1/2
7
7-1/2
+ 1/4
1/ The measurement of the relaxed waist shall be taken with the fly front fastened in the largest position.
Measure along the top edge of the waistband from folded edge to folded edge.
2/ The measurement of the outseam shall be taken from the top edge of the waistband down the outseam to
the top of the knit anklet.
3/ The measurement of the inseam shall be taken from the crotch down the inseam to the top of the knit
anklet.
4/ The measurement of the bottom shall be taken across the bottom of the leg at the top of the knit cuff,
with the bottom stretched taut, using manual tension.
4. VERIFICATION
7
