MIL-DTL-27546E
DO NOT REMOVE THIS LABEL
3.5.3 Garment instruction label. A paper instruction label measuring not less than 3-1/2 inches by
3-1/2 inches shall be included inside the sealed polyethylene bag with the jacket and trouser. The
label shall contain the following information.
"The garment shall be unpacked and shaken out,
at a room temperature of approximately 70 degrees Fahrenheit,
before fitting to insure your correct size".
3.5.4 Barcode tag. Each item shall be individually bar-coded, clearly legible and readable by
scanner. The bar-coding element shall be a 13 digit national stock number (NSN). The barcode
type shall be medium to high code density, and shall be attached so that it is completely visible on
the item when it is folded and /or packaged as specified. The label shall be attached without using
adhesive or without piercing the fabric to prevent damage to the item.
3.5.5 Patterns. The government shall furnish a complete set of patterns or a master pattern with
grade rules, to maintain uniformity and consistency in manufacturing. The government patterns
shall be used to create the contractor's working patterns. Minor modifications are permitted to
accommodate manufacturing procedures, however the design and finished measurements shall be
maintained.
TABLE II. List of pattern parts
Jacket liner
Cut pieces
Trouser liner
Cut pieces
Right front
1
Front
2
Left front
1
Back
2
Back
1
Trouser pocket
2
Left sleeve
2
Right sleeve
2
Pocket
1
3.6 Finished measurements. The finished liners shall conform to measurements as shown in Table
III and IV.
TABLE III. Jacket Liner finished measurements (inches)
Small
Medium
Large
X-Large
Tolerance
Back length 1/
26
26-1/2
26-1/2
27
+1
-3/4
1/2 Chest circ. 2/
22
24
26
28
+ 1/2 -3/8
TABLE III. Jacket Liner finished measurements (continued)
Small
Medium
Large
X-Large
Tolerance
6
