A-A-55196A
Note: The cautionary statement shall be printed in larger letters than all other lettering on the
label.
3.7 Patterns. The government shall furnish a complete set of patterns or a master pattern with
grade rules, to maintain uniformity and consistency in manufacturing. The government patterns
shall be used to create the contractor's working patterns. Minor modifications are permitted to
accommodate manufacturing procedures, however the design and finished measurements shall
be maintained.
TABLE I. Pattern Parts
Cut Pieces
Nomenclature
Body
2
Sleeves
4
Bootees 1/
4
Type I only
2
Hood
1
Tunnel
1/ May be cut in one piece so seam is on the inside of foot in lieu of heel.
3.8 Sizes and Measurements. The finished coveralls shall conform to the measurements below.
All measurements and tolerances are expressed in inches.
TABLE II. Measurements
Sizes
Chest (A)
Sleeve (B) Body (C) Leg inseam
length
length
(D)
SM/MD
27-1/8
35-5/8
37-1/2
31-1/2
LG/XLG
29-5/8
37-3/8
39-1/2
32-3/4
XXLG
32-1/8
39
41-3/8
33-3/8
Tolerance
-1/2,+ 1
-1/2,+ 1
+1
-1/2,+ 1
Sizes
Bootee depth (E)
Bootee (F)
Hood Length (G)
length
(type I only)
SM/MD
5-1/8
16-3/8
22-3/4
LG/XLG
5-1/8
17
22-3/4
XXLG
5-1/8
17-3/8
22-3/4
Tolerance
+ 1/4
+ 1/4
+ 1/4
A. Chest- Measure from one inch below the base of the armhole across the chest from folded
edge to folded edge.
B. Sleeve length- Measure straight from center of back at hood joining seam to bottom of
sleeve.
C. Body length- Measure from intersection of front seam and center of crotch seam to top of
front opening.
D. Leg inseam- Measure from the center of the crotch seam to the bottom seam of the bootee
cover.
3
